CNC lathe machining center OPTIturn S 600M

CNC lathe machining center OPTIturn S 600M is reliable equipment for performing complex turning operations. The 45° inclined bed ensures convenience when processing large parts, improving chip removal. The structure is reinforced with ribs, contributing to machining accuracy and efficient heat dissipation. Built-in measurement, automation, and cooling systems simplify operation and increase productivity.

The machining center is ideal for enterprises engaged in processing high-complexity metal parts. Its wide functionality and well-thought-out design enable both rough and finish machining of workpieces. It ensures reliable operation under intensive loads while maintaining high accuracy.

Technical specifications:
Working areas:
Chuck diameter: 320 mm
Turning length: 475 mm
Swing diameter over the bed: 570 mm
Swing diameter over the cross slide: 400 mm
Motor torque:
X axis: 11 Nm
Z axis: 11 Nm
Speed range: 30–4000 rpm
Rapid traverse speed:
X axis: 24 m/min
Z axis: 30 m/min
Electrical data:
Connection voltage: 400 V
Network frequency: 50 Hz
Total connected voltage: 40 kVA
Accuracy:
Repeatability: ±0.002 mm
Positioning accuracy: ±0.004 mm

Advantages and features:
The 45° inclined bed improves the processing of large workpieces and chip removal.
The reinforced structure with ribs ensures durability and operational accuracy.
The hydraulic three-jaw chuck with a diameter of 320 mm enhances the versatility of the equipment.
The Sauter VDI 40 turret head with 8 positions and driven tools expands machining capabilities.
The automatic lubrication system extends the service life of components.
The cooling system with a cleaning gun and built-in chip conveyor simplifies operation.
The rotating control unit and portable electronic handwheel simplify program setup.
