CNC lathe machining center OPTIturn S 500

CNC lathe machining center OPTIturn S 500 is reliable equipment equipped with SIEMENS servomotors and a powerful spindle system. The design with double-row roller and tapered bearings ensures durability and operational stability. The direct drive axes eliminate backlash, improving the accuracy of operations such as threading and contouring. The turret head with quick tool changes and automatic cooling systems make the machine convenient and efficient to operate.

The machining center is suitable for enterprises engaged in the production of complex and high-precision parts, where reliability, productivity, and minimized processing time are essential.

Technical specifications:
Working areas:
Lathe chuck diameter: 200 mm
Chuck motion control: hydraulic
Height of the peak: 300 mm
Swing diameter over the bed: 600 mm
Swing diameter over the cross slide: 450 mm
Maximum turning length: 750 mm
Motor torque:
X axis: 11 Nm
Z axis: 27 Nm
Speed range: 10–4500 rpm
Electrical data:
Motor power: 17 kW
Connection voltage: 400 V
Network frequency: 50 Hz
Total connected voltage: 50 kVA
Accuracy:
Repeatability: ±0.005 mm
Positioning accuracy: ±0.005 mm

Advantages and features:
SIEMENS servomotors ensure operational stability and precision.
A robust spindle system with constant lubrication extends the equipment's service life.
Direct drive axes eliminate backlash, improving accuracy.
Quick turret head switching and hydraulic tool changer accelerate production processes.
The cooling system and internal spindle cooling up to 20 bar maintain stable operation.
The programmable tailstock and part catcher simplify complex operations.
The chip conveyor and waste cart provide efficient waste removal.
A portable electronic handwheel with an emergency button simplifies control.

You can purchase the CNC lathe machining center OPTIturn S 500 from the company KVERB.
We offer:
Delivery across Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.

Contact our managers right now to get the best offer on the CNC lathe machining center OPTIturn S 500!
