Vertical CNC milling machining center Equiptop VMC 1100

Vertical CNC milling machining center Equiptop VMC 1100 is designed for precise processing of metal and composite materials. The machine meets modern industrial production requirements, ensuring high rigidity, performance, and accuracy in various operations.

Milling center Equiptop VMC 1100 is ideal for processing parts in mechanical engineering, aviation, automotive, electronics, and tooling industries. High spindle speed and a reliable controller guarantee stable operation even in serial and complex tasks.

This machine is an excellent choice for enterprises engaged in the production of:
Parts with high precision requirements.
Molds and dies.
Components for aviation, automotive, and electronics industries.
Elements made of non-ferrous metals and alloys.

Technical specifications Equiptop VMC 1100:

Distance from spindle to table: 120–730 mm
Spindle speed: 8000 rpm (optional 10000/12000)
Tool type: sleeve-less 16T
Maximum tool diameter: 120 mm
Maximum tool weight: 8 kg
Tool shank type: BT40
Motor: 3.5/3.5 kW
Table size: 1270x600 mm
Maximum table load capacity: 1100 kg
Travel speed along X/Y/Z axes: 18 m/min, 18 m/min, 15 m/min
Working feed rate: 1–10000 mm/min
Controller: M70/M80 or Oi-MF
Power consumption: 35 KVA
Air consumption: 6 kg/cm²

Advantages and features Equiptop VMC 1100:

Laser axis travel measurement ensures maximum positioning accuracy.
Box-type guides and reinforced base guarantee stability under high loads.
The floating tool clamping system extends spindle lifespan.
The expanded coolant tank and chip handling system maintain cleanliness and operational efficiency.
The sleeve-less tool magazine allows for quick tool changes, avoiding delays.
Controllers M70/M80 or Oi-MF provide intuitive programming and high performance.
The electrical system complies with CE standards, ensuring operator safety.

You can purchase the Vertical CNC milling machining center Equiptop VMC 1100 from the company KVERB.
We offer:
Delivery across Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.

Contact our managers right now to get the best offer on the Vertical CNC milling machining center Equiptop VMC 1100.
