Drilling machine Alzmetall AB 50/SV
SKU 100021
0 reviews
In stock
ALZMETALL
0 uah.
Shipping
- Pickup (Self-pickup) For free
- New POST Up to 100 uan
- Meest up to 100
Payment
- Оплата при отриманні
- Готівкова оплата
- Оплата по рахунку
Drilling machine Alzmetal AB 50/SV is German industrial equipment that combines advanced technology, high power, and reliability. The model is designed for drilling and thread cutting in strong materials, as well as for reaming and performing other operations with metals of varying hardness, including steel E335 (St 60). High precision and automated control ensure minimal tolerances and high productivity.
The machine is optimal for medium and large manufacturing enterprises operating in metalworking, mechanical engineering, and precision part production. It is suitable for manufacturing components, mechanical elements, and structural metal parts that require high-quality drilling and thread cutting.
Technical specifications Alzmetal AB 50/SV:
Weight: 605 kg
Height: 1950 mm
Spindle feed type: automatic
Spindle speed range (option 1): 60–1530 rpm
Spindle speed range (option 2): 50–1280 rpm
Spindle motor power (option 1): 3.6/4.3 kW
Spindle travel along Z-axis: 200 mm
Column diameter: 200 mm
Minimum distance from table to spindle: 159 mm
Maximum distance from table to spindle: 884 mm
Table area: 720 × 510 mm
Distance from spindle to column: 350 mm
Thickness of processed steel (E335): 60 mm
Advantages and features Alzmetal AB 50/SV:
Digital display for precise spindle speed control
Powerful motor up to 4.3 kW for working with hard materials
Automatic feed for simplifying complex operations
Safety system with protective guard, emergency stop, and electromagnetic clutch
Convenient control via touch screen
Ergonomic design adaptable to specific tasks
You can buy the drilling machine Alzmetal AB 50/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment
Contact our managers now to get the best offer for the drilling machine Alzmetal AB 50/SV.
The machine is optimal for medium and large manufacturing enterprises operating in metalworking, mechanical engineering, and precision part production. It is suitable for manufacturing components, mechanical elements, and structural metal parts that require high-quality drilling and thread cutting.
Technical specifications Alzmetal AB 50/SV:
Weight: 605 kg
Height: 1950 mm
Spindle feed type: automatic
Spindle speed range (option 1): 60–1530 rpm
Spindle speed range (option 2): 50–1280 rpm
Spindle motor power (option 1): 3.6/4.3 kW
Spindle travel along Z-axis: 200 mm
Column diameter: 200 mm
Minimum distance from table to spindle: 159 mm
Maximum distance from table to spindle: 884 mm
Table area: 720 × 510 mm
Distance from spindle to column: 350 mm
Thickness of processed steel (E335): 60 mm
Advantages and features Alzmetal AB 50/SV:
Digital display for precise spindle speed control
Powerful motor up to 4.3 kW for working with hard materials
Automatic feed for simplifying complex operations
Safety system with protective guard, emergency stop, and electromagnetic clutch
Convenient control via touch screen
Ergonomic design adaptable to specific tasks
You can buy the drilling machine Alzmetal AB 50/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment
Contact our managers now to get the best offer for the drilling machine Alzmetal AB 50/SV.
Specifications Drilling machine Alzmetall AB 50/SV
- Feed Automatic
- Spindle Rpm range (Option 1) 60 - 1530 RPM
- Main engine power (Option 1) 3.6/4.3 kW
- Z-travel of spindle 200 mm
- Column diameter 200 mm
- Distance spindle - table min 159 mm
- Distance spindle - table max 884 mm
- Table clamping area 720 × 510 mm
- Distance spindle to column 350 mm
- Drilling Capacity Steel (E335) 60 mm
- WEIGHT 605 kg
- HEIGHT 1 950 mm
- Share
-
-
-
-
-
-
Reviews
There are no reviews on this product yet, be the first
