Metal cutting band saw OPTIsaw SD 500AV

Metal cutting band saw OPTIsaw SD 500AV is designed for precise and high-quality cutting of various materials, including metals and aluminum. The device features advanced technologies that ensure high performance and precision.

The machine supports smoothly adjustable blade speed (20–80 m/min), making it effective for working with a variety of materials. The cutting angle is adjustable from -45° to +60°, and hydraulic material feed combined with a semi-automatic mode makes it an ideal choice for serial production.

OPTIsaw SD 500AV is suitable for:
Industrial enterprises
Metallurgical workshops
Processing non-ferrous metals and aluminum profiles
Manufacturing metal structures and elements
Producing construction details
Working with metal and plastic materials

Technical specifications of OPTIsaw SD 500AV:
Length: 2129 mm
Width/depth: 1046 mm
Height: 1687 mm
Weight: 645 kg
Motor power: 3 kW
Hydraulic pump power: 1.4 kW
Coolant pump power: 0.1 kW
Total connected load: 3.8 kW
Voltage: 400 V
Frequency: 50 Hz
Blade speed: 20–80 m/min
Blade length: 3770 mm
Blade width: 34 mm
Blade thickness: 1.1 mm
Cutting angle: from -45° to +60°
Hydraulic material feed
Semi-automatic operation

Cutting areas:
At 0°: round 355 mm, square 300 mm, rectangle 300 x 490 mm
At -45°: round 290 mm, square 250 mm, rectangle 250 x 250 mm
At +45°: round 350 mm, square 290 mm, rectangle 290 x 340 mm
At +60°: round 230 mm, square 180 mm, rectangle 180 x 220 mm

Advantages and features of OPTIsaw SD 500AV:
Heavy-duty industrial construction for durability and reliability
Quiet operation with minimal vibrations
Smoothly adjustable blade speed from 20 to 80 m/min
Semi-automatic mode for increased productivity
High cutting accuracy due to a vibration-resistant design
Adjustable cutting angle from -45° to +60° by rotating the entire saw
Bi-metal saw blade included
Easy blade tension adjustment via pressure gauge
Roller support with carbide plates for high-quality cutting results
Cooling system to prevent overheating
Hydraulic quick-clamping vise for working with large cross-sections
Smooth adjustment of blade lift speed through a feed control valve on the control panel
Micro switch for automatic stop
Intuitive control panel for simplified setup

You can purchase the metal cutting band saw OPTIsaw SD 500AV from the company KVERB.
We offer:
Delivery in Ukraine.
Official warranty and support at every stage.
Professional consultation to help you select suitable equipment.

Contact our managers right now to get a profitable offer for the metal cutting band saw OPTIsaw SD 500AV!
