Semiautomatic welding machine Helvi Maxitech EVO 506+ F4W

Semiautomatic welding machine Helvi Maxitech EVO 506+ F4W is a versatile inverter device for multi-process welding, suitable for MIG-MAG, TIG-DC, and MMA. It is equipped with microprocessor control, ensuring ease of settings and welding process stability. The machine is ideal for working with various materials and provides high-quality welding under heavy loads.

This semiautomatic welding machine is ideal for professionals working in areas such as:
Medium and light metal construction sector
Manufacturing of metal furniture and products
Automotive industry and body repair
Shipbuilding and pipelines
Production and repair of equipment requiring stable and precise results

Technical specifications:
Input voltage: 400V - 50/60Hz (three-phase power supply)
Power: 22 KVA at 60% duty cycle
Open circuit voltage:
MIG: 82 V
MMA: 82 V
TIG: 12 V
Current:
MIG: from 30 to 500 A
MMA: from 10 to 500 A
TIG: from 5 to 500 A
Duty cycle at 40°:
MIG: 500A @ 60%, 400A @ 100%
MMA: 500A @ 60%, 400A @ 100%
TIG: 500A @ 60%, 400A @ 100%
Insulation: H
Degree of protection: IP23S
Dimensions (LxWxH):
Generator: 320x650x500 mm
Feeding mechanism: 270x580x460 mm
Cooling unit: 315x630x235 mm
Trolley: 520x1050x1065 mm
Weight (packed/net): 139.6 / 131.0 kg

Advantages and features:
Microprocessor control: ensures precision and stability of the welding process. Settings are quickly and intuitively adjusted via the 3.3-inch graphical display.
Versatility of welding modes: supports MIG-MAG, TIG-DC, and MMA welding with various settings such as synergic, pulsed, double pulsed, and root welding.
Wide range of settings: allows selection between 2/4 time modes, gas feed and post-flow time adjustment, reactance, soft start, slope down, crater filler.
Additional interface connections: can connect Spool-gun, Push-Pull, and torches with analog or digital control, making the machine even more versatile for different needs.
Ability to save over 200 operator programs: allows saving settings for various tasks and easily accessing them via remote control.
Ease of updates: thanks to the USB interface, software updates can be easily carried out to improve functionality.
Increased productivity at longer distances: the ability to connect to extension cords up to 100 meters, reducing performance loss.

You can buy the semiautomatic welding machine Helvi Maxitech EVO 506+ F4W from the company KVERB.
We offer:
Delivery in Ukraine
Official warranty and technical support
Professional consultation for choosing the right equipment for your needs
Contact our managers now to get the best offer on the semiautomatic welding machine Helvi Maxitech EVO 506+ F4W!
