CNC milling machining center GMC2242bu
SKU 1920022
0 reviews
In stock
WEIDA
Shipping
- Pickup (Self-pickup) (For free)
- New POST (Up to 100 UAN)
- Meest (Up to 100 UAN)
Payment
- Payment upon receipt
- Cash payment
- Payment by bank details
CNC milling machining center GMC2242bu is an advanced machining system with five-axis control and a bridge gantry structure, ensuring exceptional rigidity and stability. Thanks to its fixed working table, the machine is ideal for machining large and heavy workpieces with high precision.
GMC2242bu is suitable for high-precision machining of complex parts in heavy industry. The machine performs milling, drilling, threading, and complex five-axis operations, making it a versatile solution for various production tasks.
This machine is an excellent choice for enterprises in mechanical engineering, aerospace, automotive, military industries, and large mold manufacturing. GMC2242bu ensures stable accuracy even during prolonged production cycles.
Technical specifications GMC2242bu:
Distance from spindle to table: 250–1250 mm.
Spindle speed: up to 18000 rpm.
Tool type: HSK63A.
Maximum tool weight: 8 kg.
Table size: 4000×2000 mm.
Maximum table load capacity: 5000 kg/m².
Traverse speed along X/Y/Z axes: 15 m/min.
Power consumption: 135 kVA.
Advantages and features GMC2242bu:
Reliable U-shaped frame construction with a honeycomb column structure provides enhanced rigidity.
All axes are equipped with linear encoders and a closed-loop system for maximum accuracy.
The liquid cooling system maintains a stable spindle temperature even under intensive use.
The chain conveyor for chip removal ensures a clean working area.
Flexibility in configuration allows the installation of automatic measurement systems for tools and workpieces.
Energy efficiency is achieved through minimal lubrication consumption on X, Y, and Z axes.
You can purchase the CNC milling machining center GMC2242bu from the company KVERB.
We offer:
Delivery across Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.
Contact our managers right now to get the best offer on the CNC milling machining center GMC2242bu.
GMC2242bu is suitable for high-precision machining of complex parts in heavy industry. The machine performs milling, drilling, threading, and complex five-axis operations, making it a versatile solution for various production tasks.
This machine is an excellent choice for enterprises in mechanical engineering, aerospace, automotive, military industries, and large mold manufacturing. GMC2242bu ensures stable accuracy even during prolonged production cycles.
Technical specifications GMC2242bu:
Distance from spindle to table: 250–1250 mm.
Spindle speed: up to 18000 rpm.
Tool type: HSK63A.
Maximum tool weight: 8 kg.
Table size: 4000×2000 mm.
Maximum table load capacity: 5000 kg/m².
Traverse speed along X/Y/Z axes: 15 m/min.
Power consumption: 135 kVA.
Advantages and features GMC2242bu:
Reliable U-shaped frame construction with a honeycomb column structure provides enhanced rigidity.
All axes are equipped with linear encoders and a closed-loop system for maximum accuracy.
The liquid cooling system maintains a stable spindle temperature even under intensive use.
The chain conveyor for chip removal ensures a clean working area.
Flexibility in configuration allows the installation of automatic measurement systems for tools and workpieces.
Energy efficiency is achieved through minimal lubrication consumption on X, Y, and Z axes.
You can purchase the CNC milling machining center GMC2242bu from the company KVERB.
We offer:
Delivery across Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.
Contact our managers right now to get the best offer on the CNC milling machining center GMC2242bu.
Specifications CNC milling machining center GMC2242bu
- Table size 4000 × 2000 mm
- Spindle speed 18000 RPM
- Cutting feed rate (X/Y/Z) 1-6000/1-6000/1-12000 mm/min
- Max. Travel For X Axis 4200
- Max. Travel For Y Axis 2200
- Max. Travel For Z Axis 1250
- Spindle Nose To Table 250-1500 mm
- Max. Table Capacity 5000
- Spindle Motor Power 56/70 kW
- Number of axes 5
- WEIGHT 68000
- LENGTH 8200
- WIDTH 7600
- HEIGHT 6600
