CNC lathe machining center OPTIturn L 50P

SKU 1920094

0 reviews

In stock

STURMER

Shipping

Pickup (Self-pickup) (For free)
New POST (Up to 100 UAN)
Meest (Up to 100 UAN)

Payment

Payment upon receipt
Cash payment
Payment by bank details

CNC lathe machining center OPTIturn L 50P is reliable equipment equipped with SIEMENS spindle and feed motors. Full enclosure with protective devices ensures safe operation. The machine supports spindle speeds up to 3500 rpm, while linear guides on all axes and an automatic lubrication system enhance precision and durability.

The machine is suitable for industrial enterprises where high machining accuracy and equipment reliability are required. Its design allows for efficient execution of complex turning operations.

Technical specifications:
Working areas:
Chuck diameter: 210 mm
Turning length: 618 mm
Height of the peak: 245 mm
Swing diameter over the bed: 490 mm
Swing diameter over the cross slide: 280 mm
Bed width: 400 mm
Motor torque:
X axis: 6 Nm
Z axis: 11 Nm
Electrical data:
Connection voltage: 400 V
Network frequency: 50 Hz
Accuracy:
Repeatability: ±0.005 mm
Positioning accuracy: ±0.005 mm

Advantages and features:
SIEMENS spindle and feed motors ensure stable operation.
Full enclosure with protective devices improves safety.
Linear guides and an automatic central lubrication system extend the equipment's service life.
The servo-hydraulic 8-position tool changer increases productivity.
The cooling system with a 110-liter tank ensures stable operation.
Electronic handwheels for X and Z axes simplify control.
Adjustable feet provide machine stability.

You can purchase the CNC lathe machining center OPTIturn L 50P from the company KVERB.
We offer:
Delivery across Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.

Contact our managers right now to get the best offer on the CNC lathe machining center OPTIturn L 50P!

Specifications CNC lathe machining center OPTIturn L 50P
