Metal cutting band saw Bomar Extend 1000.820 A 1500/2500

Metal cutting band saw Bomar Extend 1000.820 A 1500/2500 is a powerful machine with a two-column construction, designed for perpendicular cutting of massive and profile materials. It is equipped with innovative solutions such as three-way carbide blade guidance, a frame on pre-loaded linear guides, and a high saw blade (54 mm). Additionally, the machine is equipped with a brush for chip removal. The base is made from polymer concrete, which reduces vibrations during operation.

Bomar Extend 1000.820 A 1500/2500 is perfect for cutting metal workpieces and profiles at metallurgical and machine-building enterprises, as well as for applications where high precision and stable performance are required.

Technical specifications of Bomar Extend 1000.820 A 1500/2500:

Operating mode: automatic
Machine type: horizontal metal cutting band saw
Cut type: straight cut
Motor power: 7.5 kW, 3×400 V/50 Hz
Belt speed: 15–90 m/min
Belt size: 9280×54×1.6 mm
Material loading height: 800 mm
Maximum remnant length: 300 mm
Machine dimensions:
Length: 3000 mm (with loader 1500 mm)
Width: 4350 mm
Height: 3000 mm
Weight: 9500 kg

Advantages and features of Bomar Extend 1000.820 A 1500/2500:

Two-column construction: stability and accuracy when cutting large materials
Hydraulic full stroke clamping: reliable clamping of workpieces
Polymer concrete base: minimal vibrations, high cutting accuracy
Frequency converter: optimal belt speed for each material, increasing belt life and productivity
Automatic feed pressure adjustment: adapts to processing conditions
Intuitive control: touchscreen and mechanical buttons for ease of use
Flexibility in settings: integration with transport and automation systems for improved efficiency
Programming and control: process automation with settings for length and number of workpieces

You can buy metal cutting band saw Bomar Extend 1000.820 A 1500/2500 at KVERB. We offer:

Delivery in Ukraine
Official warranty and support
Consultation and assistance in selection

Contact our managers now to get the best offer on metal cutting band saw Bomar Extend 1000.820 A 1500/2500.
