Metal cutting machine Ileri Teknik Smart 350 ECO
SKU 9092-100-101
0 reviews
In stock
Ileri Teknik
0 uah.
Shipping
- Pickup (Self-pickup) For free
- New POST Up to 100 uan
- Meest up to 100
Payment
- Оплата при отриманні
- Готівкова оплата
- Оплата по рахунку
Metal cutting machine Smart 350 ECO Ileri Teknik is designed for batch straight cutting of metal workpieces such as pipes, profiles, and rolled products.
A fully automated system performs clamping, feeding, cutting, and returning without operator involvement. Material feeding is carried out by a servo drive with a ball screw pair, ensuring high positioning accuracy and repeatable cuts.
The saw head moves along hardened linear guides. The hydropneumatic drive ensures smooth blade movement through the workpiece, minimizing tool wear. Worm and helical gears guarantee stable operation even under high loads.
Technical specifications:
Motor power: 2.4–3.0 kW
Power supply: 400 V
Saw blade diameter: 350 mm
Bore diameter: 32 mm
Cutting angle: 90°
Maximum round workpiece diameter: 110 mm
Maximum square workpiece: 100×100 mm
Maximum rectangular workpiece: 120×90 mm
Feeding: servo, 1000 mm (multi-feed for long workpieces)
Air pressure: 6 bar (240 l/min)
Blade speed: 36 / 72 rpm
Weight: 1200 kg
Dimensions (L×W×H): 2200×1100×2000 mm
Advantages and features:
Full automation of all cutting processes.
Touchscreen control panel with a color display.
Servo-driven feed with a ball screw mechanism.
Smooth lowering of the saw head for perfect cuts.
Ability to cut multiple lengths on a single workpiece.
Reliable transmission with helical gears.
Coolant and lubrication system for the blade.
Optimized blade wear (TiN, TiCN, TiAIN coatings).
You can purchase the metal cutting machine Smart 350 ECO from KVERB.
We offer:
Delivery in Ukraine.
Official warranty and service support.
Professional consultation and equipment selection.
Contact our managers right now to get the best deal on the metal cutting machine Smart 350 ECO!
A fully automated system performs clamping, feeding, cutting, and returning without operator involvement. Material feeding is carried out by a servo drive with a ball screw pair, ensuring high positioning accuracy and repeatable cuts.
The saw head moves along hardened linear guides. The hydropneumatic drive ensures smooth blade movement through the workpiece, minimizing tool wear. Worm and helical gears guarantee stable operation even under high loads.
Technical specifications:
Motor power: 2.4–3.0 kW
Power supply: 400 V
Saw blade diameter: 350 mm
Bore diameter: 32 mm
Cutting angle: 90°
Maximum round workpiece diameter: 110 mm
Maximum square workpiece: 100×100 mm
Maximum rectangular workpiece: 120×90 mm
Feeding: servo, 1000 mm (multi-feed for long workpieces)
Air pressure: 6 bar (240 l/min)
Blade speed: 36 / 72 rpm
Weight: 1200 kg
Dimensions (L×W×H): 2200×1100×2000 mm
Advantages and features:
Full automation of all cutting processes.
Touchscreen control panel with a color display.
Servo-driven feed with a ball screw mechanism.
Smooth lowering of the saw head for perfect cuts.
Ability to cut multiple lengths on a single workpiece.
Reliable transmission with helical gears.
Coolant and lubrication system for the blade.
Optimized blade wear (TiN, TiCN, TiAIN coatings).
You can purchase the metal cutting machine Smart 350 ECO from KVERB.
We offer:
Delivery in Ukraine.
Official warranty and service support.
Professional consultation and equipment selection.
Contact our managers right now to get the best deal on the metal cutting machine Smart 350 ECO!
Specifications Metal cutting machine Ileri Teknik Smart 350 ECO
- Maximum Saw Blade Size 350 mm
- Maximum workpiece size at 90° Round 110 mm Square 100 × 90 mm Rectangle 120 × 90 mm
- Installed Power 4 kW
- Nominal Current 12 A
- Saw Motor Power 2.4 - 3 kW
- Blade Speed 36 / 72 m/min
- WEIGHT 1 200 kg
- LENGTH 2 200 mm
- WIDTH 1 100 mm
- HEIGHT 2 000 mm
