Hydraulic press for metal Say-Mak SHAP 1520-100

SKU 9200-110-06

0 reviews

In stock

SAY-MAK

Shipping

Pickup (Self-pickup) (For free)
New POST (Up to 100 UAN)
Meest (Up to 100 UAN)

Payment

Payment upon receipt
Cash payment
Payment by bank details

Hydraulic press for metal Say-Mak SHAP 1520-100 is versatile equipment for bending sheet metal, combining a durable design, precise mechanics, and ease of operation. Thanks to its extended worktable, the model is suitable for working with wide workpieces and ensures stable performance for both serial and custom tasks._x000d_The press is equipped with a reinforced frame, hardened blades, 5-face guide, and a table with a T-slot. The stroke adjustment system allows precise process settings, while two-hand control enhances safety. Space is provided for handling large sheets and a vertical table movement mechanism is included._x000d_Specifications: Force 100 tons Bending thickness up to 6 mm Maximum pressure 263 bar Stroke 300 mm Work zone width 1520 mm Distance between tables 680 mm Feed speed 9.0 mm/sec Working speed 5.0 mm/sec Return speed 10.0 mm/sec Table size 500×1520 mm Table hole diameter 100 mm Motor power 7.5 kW Dimensions (W×L×H) 1000×2630×2275 mm Weight 2500 kg Advantages and features: Hardened blades Reinforced welded frame Prismatic guide (5 faces) Lower table with T-slot Smooth stroke adjustment Manometer Adjustable lower blade Table lifting/lowering mechanism Pressure adjustment valve Spacious work area Safe two-hand control You can purchase the hydraulic press for metal Say-Mak SHAP 1520-100 from KVERB company. We provide: Delivery in Ukraine Official warranty and service Assistance in selecting equipment for your tasks Contact us to get the latest offer on the hydraulic press Say-Mak SHAP 1520-100.

Specifications Hydraulic press for metal Say-Mak SHAP 1520-100
