Hydraulic press for metal Say-Mak SHAP 1020-150
SKU 9200-110-07
0 reviews
In stock
SAY-MAK
Shipping
- Pickup (Self-pickup) (For free)
- New POST (Up to 100 UAN)
- Meest (Up to 100 UAN)
Payment
- Payment upon receipt
- Cash payment
- Payment by bank details
Hydraulic press for metal Say-Mak SHAP 1020-150 is professional equipment for bending metal sheets, combining a durable design, high power, and precision. Thanks to hardened blades, adjustable components, and convenient operation, the press ensures stable performance when processing workpieces up to 10 mm thick._x000d_Hydraulic press Say-Mak SHAP 1020-150 is suitable for: Mechanical engineering enterprises Metalworking productions Factories manufacturing metal enclosures Manufacturers of cabinets, ventilation, and construction structures Companies working with large sheets Specifications: Force 150 tons Bending thickness up to 10 mm Maximum pressure 244 bar Stroke 300 mm Work zone width 1020 mm Distance between tables 610 mm Feed speed 9 mm/sec Working speed 5 mm/sec Return speed 10 mm/sec Table size 600×1020 mm Lower table hole diameter 100 mm Motor power 11 kW Width 1000 mm Length 2110 mm Height 2450 mm Weight 2400 kg Advantages and features: Hardened blades Welded steel frame Prism with five working faces Table with T-slot Smooth stroke adjustment Manometer Adjustable lower blade Lifting mechanism for the worktable Pressure adjustment valve Spacious area for working with large sheets Two-hand control for safe operation You can purchase the hydraulic press for metal Say-Mak SHAP 1020-150 from KVERB company. We offer: Delivery in Ukraine Official warranty and technical support Professional consultation for equipment selection Contact us to get the best offer on the hydraulic press for metal Say-Mak SHAP 1020-150.
Specifications Hydraulic press for metal Say-Mak SHAP 1020-150
- CAPACITY 150 t
- MAX. WORKING PRESSURE 244 bar
- STROKE 300 mm
- Working lenght 1 020 mm
- Power of main engine 11 kW
- Slider speed without load 9 mm/s
- Slider working speed 5 mm/s
- Slider return speed 10 mm/s
- WEIGHT 2 400 kg
- LENGTH 2 110 mm
- WIDTH 1 000 mm
- HEIGHT 2 450 mm
