Lock forming machine Schlebach EPM-25

SKU 8855-222-002

0 reviews

In stock

SCHLEBACH

Shipping

Pickup (Self-pickup) (For free)
New POST (Up to 100 UAN)
Meest (Up to 100 UAN)

Payment

Payment upon receipt
Cash payment
Payment by bank details

Lock forming machine Schlebach EPM-25 is a compact solution for forming a double standing seam of 25 mm from short, conical, or tapered panels. The device is suitable for two-pass processing of blanks at construction sites and in confined spaces. Thanks to its low weight and transport handles, the machine is easy to move and install.

It is suitable for manufacturing one-sided profiles with a minimum panel length of 250 mm. The design provides flexibility and speed when forming non-standard panels from sheet material.

Schlebach EPM-25 is suitable for:
Companies working at construction sites
Small-scale manufacturers and private craftsmen
Organizations that require a mobile machine for non-standard panels
Enterprises where an additional or backup machine is needed

Technical specifications:
Drive power: 1.1 kW
Forming speed: 8.5 m/min
Forming stages: 7
Minimum panel length: 250 mm
Feed height: 870 mm
Axial dimension: 50 mm
Weight: 180 kg

Advantages and features:
The most affordable model in the range
Suitable for short, conical, and tapered panels
Formation of one-sided profile in two passes
Compact body and low weight
Convenient transportation thanks to handles

You can buy the lock forming machine Schlebach EPM-25 from KVERB company:
We offer:
Delivery throughout Ukraine
Official warranty and technical support
Consultations on selecting equipment for your tasks

Contact our managers and get a favorable offer for Schlebach EPM-25.

Specifications Lock forming machine Schlebach EPM-25

Supply voltage 400 V / 50 Hz / 3 Ph.
Drive power 1.1 kW
Operating speed 8.5 m/min
Forming stages 7 stations
Shortest panel length 250
Infeed height 870
Processable materials <ul> <li>Titanium zinc up to 0.8 mm</li> <li>Copper up to 0.8 mm</li> <li>Aluminium up to 0.8 mm</li> <li>Sheet steel (galvanized and coated) up to 0.7 mm</li> <li>Stainless steel up to 0.5 mm</li> </ul>
WEIGHT 180 kg
LENGTH 950/1250
WIDTH 1250 mm
HEIGHT 1 070 mm
