Bead roller Prinzing SME 80/3 P
SKU 0506-555-55
0 reviews
In stock
PRINZING
Shipping
- Pickup (Self-pickup) (For free)
- New POST (Up to 100 UAN)
- Meest (Up to 100 UAN)
Payment
- Payment upon receipt
- Cash payment
- Payment by bank details
Bead roller Prinzing SME 80/3 P is industrial equipment for bending and processing sheet metal and pipes up to 2 mm thick. It is equipped with a powerful drive with options for single-stage, two-stage, or stepless mode, and control is performed via a foot pedal with a safety system or through a PLC controller.
Prinzing SME 80/P is designed for professional use in production workshops and industrial facilities. It is suitable for processing ventilation elements, frames, shaped parts, and other metal components requiring precise bending and repeatability.
Technical specifications:
Type of drive: single-stage, two-stage, or stepless
Control: foot pedal with a safety system or PLC with a display
Upper shaft feed: manual or motorized
Workpiece support: electrically adjustable with a guiding device for pipes
Distance between rollers: 80 mm
Working depth: 315 mm
Metal thickness: up to 2 mm
Advantages and features:
The choice of drive type allows for precise speed adaptation to the task.
Foot control ensures convenience and safety.
The PLC with a touchscreen simplifies parameter setup and monitoring.
The model is designed for processing large workpieces.
Additional equipment expands the machine's functionality and increases productivity.
You can purchase the bead roller Prinzing SME 80/3 P from the KVERB company.
We offer:
Delivery in Ukraine
Official warranty and technical support
Professional consultation to choose the equipment that suits your needs
Contact our managers right now to get the best offer on the bead roller Prinzing SME 80/3 P!
Prinzing SME 80/P is designed for professional use in production workshops and industrial facilities. It is suitable for processing ventilation elements, frames, shaped parts, and other metal components requiring precise bending and repeatability.
Technical specifications:
Type of drive: single-stage, two-stage, or stepless
Control: foot pedal with a safety system or PLC with a display
Upper shaft feed: manual or motorized
Workpiece support: electrically adjustable with a guiding device for pipes
Distance between rollers: 80 mm
Working depth: 315 mm
Metal thickness: up to 2 mm
Advantages and features:
The choice of drive type allows for precise speed adaptation to the task.
Foot control ensures convenience and safety.
The PLC with a touchscreen simplifies parameter setup and monitoring.
The model is designed for processing large workpieces.
Additional equipment expands the machine's functionality and increases productivity.
You can purchase the bead roller Prinzing SME 80/3 P from the KVERB company.
We offer:
Delivery in Ukraine
Official warranty and technical support
Professional consultation to choose the equipment that suits your needs
Contact our managers right now to get the best offer on the bead roller Prinzing SME 80/3 P!
Specifications Bead roller Prinzing SME 80/3 P
- Drive Type Electromechanical
- Metal processing thickness 2.00 mm
- Engine power 1.50 kW
- Working depth 315 mm
- Roll gauge 80 mm
- Working speed 0 - 20 m/min
- WEIGHT 28.0 kg
- LENGTH 1000 mm
- WIDTH 900 mm
- HEIGHT 1500 mm
