Plate rolling machine Isitan 4R HMS 3100x250

Plate rolling machine Isitan 4R HMS 3100x250 is high-precision equipment designed for sheet metal bending in industrial production. The durable welded construction and modern technologies make it an effective solution for processing various types of metal. The machine complies with CE safety standards.

Isitan 4R HMS 3100x250 is suitable for working with sheet metal, aluminum, and stainless steel. It is used in the production of pipes, reservoirs, ventilation systems, and structural elements. The ability to perform conical bending allows the formation of complex geometric shapes.

This equipment is ideal for enterprises in the metalworking, machine-building, and construction industries. It is particularly efficient in workshops where large workpieces are processed with high precision requirements.

Technical specifications of Isitan 4R HMS 3100x250:
Working bending length: 3100 mm
Pre-bending thickness: 5/7 mm
Maximum bending thickness: 7/9 mm
Top and bottom roll diameter: 250 mm
Side roll diameter: 200 mm
Minimum bending diameter: 375/1250 mm
Motor power: 7.5 + 1.5 kW
Working speed: 5 m/min
Dimensions (L x W x H): 5000 x 1500 x 1370 mm
Weight: 6800 kg

Advantages and features of Isitan 4R HMS 3100x250:
Hydraulic control system ensures precise roll positioning adjustment.
Overload protection extends the equipment's service life.
Electric drive for the top roll via planetary gearbox ensures stable and powerful operation.
Digital control panel simplifies the setup and process monitoring.
Conical bending allows the creation of non-standard products.
Reinforced construction made from SAE 1050 (CK 45) steel with induction hardening.
Hydraulic side supports and top lifting mechanism are suitable for working with large parts.
Adjustable speed ensures optimal productivity.
Polished and ground rolls reduce the risk of material damage.
