Metal rolling machine Isitan 4R HMS
2550x180
SKU 9091-201-090
0 reviews
In stock
ISITAN
0 uah.
Shipping
- Pickup (Self-pickup) For free
- New POST Up to 100 uan
- Meest up to 100
Payment
- Оплата при отриманні
- Готівкова оплата
- Оплата по рахунку
Metal rolling machine Isitan 4R HMS 2550x180 is a machine designed for precise bending of sheets of various thicknesses. High power, reliable construction, and hydraulic control ensure stable operation when processing aluminum, stainless steel, and carbon steel. The equipment is ideal for processing medium-thickness metal in both serial and individual production.
Isitan 4R HMS 2550x180 is used for forming cylindrical and conical parts. The precise rolls provide the required bending radius and allow work with materials of varying densities without compromising quality.
These rollers are used in machine engineering, construction, ventilation, and tank production. The machine is suitable for the production of:
Metal pipes and tanks
Industrial equipment enclosures
Ventilation systems
Structural elements and frames
Technical specifications of Isitan 4R HMS 2550x180:
Bending length: 2550 mm
Preliminary bending thickness: 3–4 mm
Maximum bending thickness: 4–6 mm
Top and bottom roll diameter: 180 mm
Side roll diameter: 150 mm
Minimum bending diameter: 270/900 mm
Motor power: 4.0 + 1.5 kW
Working speed: 5 m/min
Dimensions: 4350 x 1350 x 1290 mm
Weight: 3700 kg
Advantages and features of Isitan 4R HMS 2550x180:
Hydraulic control for precise adjustment of roll positions
Sturdy welded frame is resistant to long-term loads
Digital indicators ensure precise process control
Hydraulic head opening speeds up removal of finished parts
Planetary gearbox evenly distributes the load
Conical bending allows the creation of complex-shaped parts
Hydraulic balancing system increases working accuracy
CE compliance guarantees safe operation
You can purchase metal rolling machine Isitan 4R HMS 2550x180 at KVERB.
Contact our managers now and get an attractive offer on metal rolling machine Isitan 4R HMS 2550x180.
Isitan 4R HMS 2550x180 is used for forming cylindrical and conical parts. The precise rolls provide the required bending radius and allow work with materials of varying densities without compromising quality.
These rollers are used in machine engineering, construction, ventilation, and tank production. The machine is suitable for the production of:
Metal pipes and tanks
Industrial equipment enclosures
Ventilation systems
Structural elements and frames
Technical specifications of Isitan 4R HMS 2550x180:
Bending length: 2550 mm
Preliminary bending thickness: 3–4 mm
Maximum bending thickness: 4–6 mm
Top and bottom roll diameter: 180 mm
Side roll diameter: 150 mm
Minimum bending diameter: 270/900 mm
Motor power: 4.0 + 1.5 kW
Working speed: 5 m/min
Dimensions: 4350 x 1350 x 1290 mm
Weight: 3700 kg
Advantages and features of Isitan 4R HMS 2550x180:
Hydraulic control for precise adjustment of roll positions
Sturdy welded frame is resistant to long-term loads
Digital indicators ensure precise process control
Hydraulic head opening speeds up removal of finished parts
Planetary gearbox evenly distributes the load
Conical bending allows the creation of complex-shaped parts
Hydraulic balancing system increases working accuracy
CE compliance guarantees safe operation
You can purchase metal rolling machine Isitan 4R HMS 2550x180 at KVERB.
Contact our managers now and get an attractive offer on metal rolling machine Isitan 4R HMS 2550x180.
Specifications Metal rolling machine Isitan 4R HMS 2550x180
- Working speed 5 m/min
- Drive Type Electromechanical
- Metal processing thickness 4/6 mm
- Engine power 4.0+1.5 kW
- Working length 2550 mm
- Shaft diameter 180 mm
- Min. bending diameter 270 / 900 mm
- WEIGHT 3700 кг
- LENGTH 4350 mm
- WIDTH 1350 mm
- HEIGHT 1290 mm
