Metal rolling machine Isitan 4R HMS 2550x150

Metal rolling machine Isitan 4R HMS 2550x150 is a machine designed for precise and stable bending of metal sheets. It is suitable for processing light and medium metals, including aluminum, stainless steel, and carbon steel. The reliable construction and modern technological solutions ensure high-quality results even for complex operations.

The Isitan 4R HMS 2550x150 model is used for bending metal sheets into cylindrical and conical shapes, as well as for manufacturing parts with varying diameters. The equipment is in demand in the production of ventilation systems, pipelines, tanks, enclosures, and other products.

These rollers are ideal for use in machine engineering, shipbuilding, and construction. They allow the creation of metal structures of various complexities with high precision and consistent results.

Technical specifications of Isitan 4R HMS 2550x150:

Maximum bending length: 2550 mm
Preliminary bending thickness: 2/3 mm
Maximum bending thickness: 3/4 mm
Top and bottom roll diameter: 150 mm
Side roll diameter: 130 mm
Minimum bending diameter: 225/750 mm
Motor power: 2.2 + 1.1 kW
Working speed: 6 m/min
Hydraulic tank capacity: 40 l
Dimensions (L x W x H): 4300 x 1150 x 1110 mm
Weight: 3230 kg

Advantages and features of Isitan 4R HMS 2550x150:

Hydraulic control – the lower and side rolls move with the hydraulic system, ensuring uniform pressure and bending accuracy
Sturdy construction – made with a welded steel frame, providing durability and reliability
Overload protection – equipped with a system that prevents damage during excessive load
Digital roll position indicators – allows easy control of bending parameters for high precision
Ease of use – mobile control panel allows easy operation, and the hydraulic head opening system simplifies the removal of finished parts
Adjustable working speed – operator can set the required working mode based on task requirements
European quality standard – CE compliance ensures safety

You can purchase metal rolling machine Isitan 4R HMS 2550x150 at KVERB.
Contact our managers now and get an attractive offer on metal rolling machine Isitan 4R HMS 2550x150.
