Sheet metal rolling machine LIMA SSL 3000
SKU 4444-666-109
0 reviews
In stock
LIMA
Shipping
- Pickup (Self-pickup) (For free)
- New POST (Up to 100 UAN)
- Meest (Up to 100 UAN)
Payment
- Payment upon receipt
- Cash payment
- Payment by bank details
LIMA SSL 3000 are equipment designed for forming semicircular gutters and preliminary processing of sheet metal before further joining. The machine combines the functions of bending and strengthening (vulcanizing) the gutter edges in a single process.
The LIMA SSL 3000 model is intended for producing semicircular gutters from flat sheets. With just two passes, it produces a smoothly bent blank with reinforced edges. The machine can also be used for bending metal to prepare blanks for subsequent longitudinal welding.
This machine is ideal for manufacturing enterprises specializing in the production of drainage systems, roofing elements, and metal pipes. Due to its ease of use, it becomes indispensable equipment for both small and large-scale production working with thin sheet metal.
Technical specifications of LIMA SSL 3000:
Blank length: 3 m
Maximum material thickness:
Steel – up to 0.7 mm
Aluminum – up to 0.8 mm
Titanium zinc – up to 0.8 mm
Copper – up to 1 mm
Roller diameters for gutters: 250 mm, 280 mm, 333 mm, 400 mm
Control system: PLC (programmable logic controller), manual and automatic operation modes
Power supply: 380V, 50Hz, 16A
Dimensions:
Length – 3650 mm
Width – 1000 mm
Height – 1500 mm
Weight: 500 kg
Advantages and features:
Multifunctionality. One machine provides manufacturing of gutters of various sizes and bending of sheet metal for subsequent joining.
Accuracy and speed. Two operations – and a ready semicircular gutter.
Automated control. PLC system adjusts the operating time via a potentiometer and allows choosing between manual and automatic modes.
Stability and reliability. Quality materials and thoughtful design ensure the equipment's durability.
Ergonomics. Convenient sheet loading and bending radius adjustment for precise gutter forming.
You can purchase sheet metal rolling machine LIMA SSL 3000 at KVERB. We offer:
Delivery in Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.
The LIMA SSL 3000 model is intended for producing semicircular gutters from flat sheets. With just two passes, it produces a smoothly bent blank with reinforced edges. The machine can also be used for bending metal to prepare blanks for subsequent longitudinal welding.
This machine is ideal for manufacturing enterprises specializing in the production of drainage systems, roofing elements, and metal pipes. Due to its ease of use, it becomes indispensable equipment for both small and large-scale production working with thin sheet metal.
Technical specifications of LIMA SSL 3000:
Blank length: 3 m
Maximum material thickness:
Steel – up to 0.7 mm
Aluminum – up to 0.8 mm
Titanium zinc – up to 0.8 mm
Copper – up to 1 mm
Roller diameters for gutters: 250 mm, 280 mm, 333 mm, 400 mm
Control system: PLC (programmable logic controller), manual and automatic operation modes
Power supply: 380V, 50Hz, 16A
Dimensions:
Length – 3650 mm
Width – 1000 mm
Height – 1500 mm
Weight: 500 kg
Advantages and features:
Multifunctionality. One machine provides manufacturing of gutters of various sizes and bending of sheet metal for subsequent joining.
Accuracy and speed. Two operations – and a ready semicircular gutter.
Automated control. PLC system adjusts the operating time via a potentiometer and allows choosing between manual and automatic modes.
Stability and reliability. Quality materials and thoughtful design ensure the equipment's durability.
Ergonomics. Convenient sheet loading and bending radius adjustment for precise gutter forming.
You can purchase sheet metal rolling machine LIMA SSL 3000 at KVERB. We offer:
Delivery in Ukraine.
Official warranty and technical support.
Professional consultation to select the equipment that suits your needs.
Specifications Sheet metal rolling machine LIMA SSL 3000
- Drive Type Electromechanical
- Metal processing thickness 0.7 mm
- Working length 3000 mm
- WEIGHT 500 kg
- LENGTH 3650 mm
- WIDTH 1000 mm
- HEIGHT 1500 mm
