Pipe bending machine Nargesa CC90 CNC

Pipe bending machine Nargesa CC90 CNC is a modern next-generation machine for high-precision bending of metal profiles without the use of a mandrel. Equipped with a touchscreen control panel, it provides ease of setup and operational efficiency. Thanks to Industry 4.0 technologies, this machine is one of the most productive and reliable in its class.

The machine is designed for bending pipes of various shapes, including round, oval, square, and rectangular. It is suitable for working with materials such as steel, aluminum, stainless steel, copper, and others. The mandrel-free bending technology ensures excellent quality with minimal deformation and material strength loss.

The pipe bending machine is perfect for:

Metalworking enterprises
Furniture manufacturers
Automotive and shipbuilding industries
Production of handrails, frames, and decorative structures
Construction industry

The machine will be indispensable for companies engaged in mass production as well as workshops handling custom orders.

Technical specifications of the Nargesa CC90 CNC machine:

Maximum working pipe diameter from S275 steel – 90 mm or 3” Schedule 40
Maximum aluminum pipe diameter – 88.9 mm x 10 mm
Maximum stainless steel pipe diameter 304/316 – 88.9 mm x 4 mm
Maximum square profile size – 60x60x4 mm
Maximum bending angle – 180°
Minimum bending radius – 3 pipe diameters
Maximum bending radius – 390 mm
Bend repeatability accuracy – ±0.1°
Automatic bending speed adjustment – from 0.75 to 2.2 m/min
7” touchscreen display supporting over 20 languages
Storing up to 10,000 bending programs
Programming up to 50 different angles on a single part
Automatic unlocking system for easy material extraction
Motor power – 2.2 kW (3 hp)
Machine weight – 860 kg

Advantages and features of the Nargesa CC90 CNC:

High bending accuracy – CNC control minimizes deviations in bend repeatability
Ease of use – the touchscreen allows for quick parameter adjustments
Quick tool change – the process takes no more than 60 seconds
Durability – hardened steel molds and bronze alloy counter molds prevent material damage
Safety – the machine complies with CE standards and is equipped with a foot control for safe operation
Flexibility – the ability to bend different materials and select the bending direction

You can purchase the pipe bending machine Nargesa CC90 CNC from KVERB. We offer:

Delivery in Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment for your needs

Contact our managers now to get the best offer on the Nargesa CC90 CNC pipe bending machine. At KVERB, you will find pipe bending machines from leading manufacturers such as KRAFT&DELE, Sahinler, Say-Mak, and many others, meeting modern quality and efficiency standards.

In addition to bending machines, we also offer sheet metal cutting machines and other machines used for producing ventilation systems, construction profiles, and specialized products.

Our company specializes in the sale and servicing of metalworking equipment, including pipe bending machines, rollers, guillotines, edge rolling machines, and other industrial machines. We work with trusted manufacturers and provide high-level technical support at all stages of cooperation.

We also offer repair and maintenance services for industrial machines and other metal-cutting equipment. Our specialists ensure the longevity and uninterrupted operation of the equipment
