Drilling machine Alzmetall AB-FLOW 40/SV

SKU 100023

0 reviews

In stock

ALZMETALL

0 uah.

Shipping

Pickup (Self-pickup) For free
New POST Up to 100 uan
Meest up to 100

Payment

Оплата при отриманні
Готівкова оплата
Оплата по рахунку

Drilling machine Alzmetal AB-FLOW 40/SV is a versatile piece of equipment for drilling, thread cutting, and thermal drilling of holes in metal. It combines high precision, operational stability, and productivity, making it an optimal choice for professional industrial use.

The model is designed for processing various grades of steel, including E335 (St 60), with the capability to drill holes up to 40 mm in diameter and cut threads up to M30. Thanks to the der spanlose Fertigungsprozess technology, the process takes place without chip formation, increasing efficiency and reducing material waste.

The machine is in demand at mechanical engineering, metallurgical, repair, and manufacturing enterprises where the production of high-precision parts, housing elements, fastening structures, and other components requiring reliable machining is necessary.

Technical specifications Alzmetal AB-FLOW 40/SV:
Weight: 470 kg
Height: 1885 mm
Spindle feed type: automatic
Spindle speed range (option 1): 140–4000 rpm
Spindle motor power (option 1): 4 kW
Spindle travel along Z-axis: 160 mm
Column diameter: 145 mm
Minimum distance from table to spindle: 147 mm
Maximum distance from table to spindle: 688 mm
Table area: 615 × 430 mm
Distance from spindle to column: 300 mm
Thickness of processed steel (E335): 40 mm

Advantages and features Alzmetal AB-FLOW 40/SV:
Automatic spindle feed for high productivity
Electromagnetic feed clutch with overload protection
Electric spindle speed adjustment
Built-in cooling system for high-quality machining
Durable construction with wear-resistant paint coating
Motor protection with insulation class F (155°)
LED work area lighting
Intuitive controls

You can buy the drilling machine Alzmetal AB-FLOW 40/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment

Contact our managers to get the best offer for Alzmetal AB-FLOW 40/SV.

Specifications Drilling machine Alzmetall AB-FLOW 40/SV
