Drilling machine Alzmetall AB-FLOW 40 iTRONIC

SKU 100025

0 reviews

In stock

ALZMETALL

0 uah.

Shipping

Pickup (Self-pickup) For free
New POST Up to 100 uan
Meest up to 100

Payment

Оплата при отриманні
Готівкова оплата
Оплата по рахунку

Drilling machine Alzmetal AB-FLOW 40 iTRONIC is modern high-tech equipment for precise chipless drilling and thread cutting using thermal drilling technology. The machine is suitable for metalworking and series production, combining automation, high power, and control via a touchscreen display.

The model is designed for working with steel and other materials, ensuring high quality and durability of threaded connections. The use of chipless forming technology increases the strength of products and reduces tool wear. The machine effectively processes steel E335 (St 60) and is suitable for mechanical engineering enterprises, metalworking plants, manufacturers of pipeline systems and fasteners, as well as for serial and mass production.

Technical specifications Alzmetal AB-FLOW 40 iTRONIC:
Weight: 470 kg
Height: 2110 mm
Spindle feed type: automatic
Spindle speed range (option 1): 140–4000 rpm
Spindle motor power (option 1): 4 kW
Spindle travel along Z-axis: 160 mm
Column diameter: 145 mm
Minimum distance from table to spindle: 147 mm
Maximum distance from table to spindle: 688 mm
Table area: 615 × 430 mm
Distance from spindle to column: 300 mm
Thickness of processed steel (E335): 40 mm

Advantages and features:
Automatic spindle speed adjustment based on material and operation type
Thread cutting function with separate control of right and left rotation
7” LCD touchscreen for convenient operation
Safety system: spindle protection, electromagnetic feed protection, main switch, emergency stop button
Dual cooling system (Coolant A and Coolant B) for extended workloads
Automatic drilling depth control and precise adjustment
Robust construction with high column rigidity and a durable machine table

You can buy the drilling machine Alzmetal AB-FLOW 40 iTRONIC from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment

Contact our managers now to get the best offer for the drilling machine Alzmetal AB-FLOW 40 iTRONIC.

Specifications Drilling machine Alzmetall AB-FLOW 40 iTRONIC
