Drilling machine Alzmetall AB 40/SV
SKU 100020
0 reviews
In stock
ALZMETALL
0 uah.
Shipping
- Pickup (Self-pickup) For free
- New POST Up to 100 uan
- Meest up to 100
Payment
- Оплата при отриманні
- Готівкова оплата
- Оплата по рахунку
Drilling machine Alzmetal AB 40/SV is high-precision equipment for drilling and thread cutting in strong materials. German technology and a reliable design ensure stable operation in both serial and single production, as well as a long service life.
The model is used for processing metal workpieces, including steel E335 (St 60). The machine can drill holes up to 50 mm in diameter and cut threads up to M30, making it in demand in mechanical engineering, the aviation and automotive industries, metalworking enterprises, and repair workshops.
A wide speed range from 70 to 4000 rpm allows performing both standard and high-precision operations, including manufacturing parts with complex configurations.
Technical specifications Alzmetal AB 40/SV:
Weight: 470 kg
Height: 1885 mm
Spindle feed type: automatic
Spindle speed range (option 1): 70–4000 rpm
Spindle motor power (option 1): 1.8/2.9 kW
Spindle travel along Z-axis: 160 mm
Column diameter: 145 mm
Minimum distance from table to spindle: 147 mm
Maximum distance from table to spindle: 688 mm
Table area: 615 × 430 mm
Distance from spindle to column: 300 mm
Thickness of processed steel (E335): 50 mm
Advantages and features Alzmetal AB 40/SV:
Digital speed display and automatic depth control
Smooth electronic speed adjustment
Electromagnetic clutch with overload protection and motor thermal contact
Durable DD-structured lacquer coating for corrosion protection
Possibility to install a cooling system and automatic feed
You can buy the drilling machine Alzmetal AB 40/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment
Contact our managers now to get the best offer for the drilling machine Alzmetal AB 40/SV.
The model is used for processing metal workpieces, including steel E335 (St 60). The machine can drill holes up to 50 mm in diameter and cut threads up to M30, making it in demand in mechanical engineering, the aviation and automotive industries, metalworking enterprises, and repair workshops.
A wide speed range from 70 to 4000 rpm allows performing both standard and high-precision operations, including manufacturing parts with complex configurations.
Technical specifications Alzmetal AB 40/SV:
Weight: 470 kg
Height: 1885 mm
Spindle feed type: automatic
Spindle speed range (option 1): 70–4000 rpm
Spindle motor power (option 1): 1.8/2.9 kW
Spindle travel along Z-axis: 160 mm
Column diameter: 145 mm
Minimum distance from table to spindle: 147 mm
Maximum distance from table to spindle: 688 mm
Table area: 615 × 430 mm
Distance from spindle to column: 300 mm
Thickness of processed steel (E335): 50 mm
Advantages and features Alzmetal AB 40/SV:
Digital speed display and automatic depth control
Smooth electronic speed adjustment
Electromagnetic clutch with overload protection and motor thermal contact
Durable DD-structured lacquer coating for corrosion protection
Possibility to install a cooling system and automatic feed
You can buy the drilling machine Alzmetal AB 40/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional consultation to help you choose the right equipment
Contact our managers now to get the best offer for the drilling machine Alzmetal AB 40/SV.
Specifications Drilling machine Alzmetall AB 40/SV
- Feed Automatic
- Spindle Rpm range (Option 1) 70 - 4000 RPM
- Main engine power (Option 1) 1.8/2.9 kW
- Z-travel of spindle 160 mm
- Column diameter 145 mm
- Distance spindle - table min 147 mm
- Distance spindle - table max 688 mm
- Table clamping area 615 × 430 mm
- Distance spindle to column 300 mm
- Drilling Capacity Steel (E335) 50 mm
- WEIGHT 470 kg
- HEIGHT 1 885 mm
