Drilling machine Alzmetall AB 34/SV
SKU 100019
0 reviews
In stock
ALZMETALL
0 uah.
Shipping
- Pickup (Self-pickup) For free
- New POST Up to 100 uan
- Meest up to 100
Payment
- Оплата при отриманні
- Готівкова оплата
- Оплата по рахунку
Drilling machine Alzmetal AB 34/SV is industrial equipment for drilling and thread cutting, combining high precision and power. A robust construction and modern technologies make this model an optimal choice for enterprises, workshops, and production facilities.
The model is used for processing steel, cast iron, and non-ferrous metals. It is suitable for drilling holes up to 40 mm in diameter in steel E335 (St 60) and thread cutting up to M24. It is effectively applied in mechanical engineering, the aviation and automotive industries, as well as in repair workshops.
Technical specifications Alzmetal AB 34/SV:
Weight: 470 kg
Height: 1865 mm
Spindle feed type: automatic
Spindle speed range (option 1): 100–1800 rpm
Spindle motor power (option 1): 0.6/1.8 kW
Spindle travel along Z-axis: 160 mm
Column diameter: 145 mm
Minimum distance from table to spindle: 147 mm
Maximum distance from table to spindle: 688 mm
Table area: 615 × 430 mm
Distance from spindle to column: 300 mm
Thickness of processed steel (E335): 40 mm
Advantages and features Alzmetal AB 34/SV:
Digital depth display for precise drilling
Automatic feed with electromagnetic clutch for efficient operation
Durable steel construction resistant to heavy loads
Safety systems: emergency stop, spindle protection, lockable main switch
Smooth speed adjustment and digital display
Optional configurations available — automatic depth control, cooling system, thread cutting device with foot switch
You can buy the drilling machine Alzmetal AB 34/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional assistance in equipment selection
Contact our specialists to get a competitive offer for Alzmetal AB 34/SV and choose the optimal configuration for your production needs.
The model is used for processing steel, cast iron, and non-ferrous metals. It is suitable for drilling holes up to 40 mm in diameter in steel E335 (St 60) and thread cutting up to M24. It is effectively applied in mechanical engineering, the aviation and automotive industries, as well as in repair workshops.
Technical specifications Alzmetal AB 34/SV:
Weight: 470 kg
Height: 1865 mm
Spindle feed type: automatic
Spindle speed range (option 1): 100–1800 rpm
Spindle motor power (option 1): 0.6/1.8 kW
Spindle travel along Z-axis: 160 mm
Column diameter: 145 mm
Minimum distance from table to spindle: 147 mm
Maximum distance from table to spindle: 688 mm
Table area: 615 × 430 mm
Distance from spindle to column: 300 mm
Thickness of processed steel (E335): 40 mm
Advantages and features Alzmetal AB 34/SV:
Digital depth display for precise drilling
Automatic feed with electromagnetic clutch for efficient operation
Durable steel construction resistant to heavy loads
Safety systems: emergency stop, spindle protection, lockable main switch
Smooth speed adjustment and digital display
Optional configurations available — automatic depth control, cooling system, thread cutting device with foot switch
You can buy the drilling machine Alzmetal AB 34/SV from KVERB. We offer:
Delivery throughout Ukraine
Official warranty and technical support
Professional assistance in equipment selection
Contact our specialists to get a competitive offer for Alzmetal AB 34/SV and choose the optimal configuration for your production needs.
Specifications Drilling machine Alzmetall AB 34/SV
- Feed Automatic
- Spindle Rpm range (Option 1) 100 - 1800 RPM
- Main engine power (Option 1) 0.6/1.8 kW
- Z-travel of spindle 160 mm
- Column diameter 145 mm
- Distance spindle - table min 147 mm
- Distance spindle - table max 688 mm
- Table clamping area 615 × 430 mm
- Distance spindle to column 300 mm
- Drilling Capacity Steel (E335) 40 mm
- WEIGHT 470 kg
- HEIGHT 1 865 mm
