Band saw machines Pilous ARG 235

Metal cutting band saw machine Pilous ARG 235 is an improved version of one of the most popular models in its category, providing high accuracy and productivity when cutting various materials. The machine is equipped with a new frame design for the saw blade and modern technological solutions, which enhance its efficiency and reliability in operation. It is designed to cut metal workpieces with a maximum diameter of up to 235 mm and a rectangular section of up to 280 x 180 mm, making it ideal for working with various types of metals, including stainless steel and tool steels.

For whom and for what it is used:
The metal cutting band saw machine Pilous ARG 235 is a versatile tool that is suitable for use in various fields, from workshops and service centers to large industrial enterprises. It is perfect for precise cutting of metals in large volumes, as well as for complex work with long and heavy workpieces. It can be used in areas such as mechanical engineering, repair and maintenance, as well as in metalworking industries where high productivity and cutting accuracy are required.

Technical specifications:
Maximum cutting diameter: 235 mm
Maximum rectangular workpiece dimensions: 280 x 180 mm
Saw blade size: 27 x 0.9 mm, available in various versions for cutting different types of materials
Saw speed: Dual speed (40 and 80 m/min), adjustable using an industrial electric motor with a worm gear transmission
Cooling system: Full cooling system with a powerful pump, adjustable flow on both guides
Control system: Convenient ergonomic control elements located on an ergonomically designed panel for both electrical and hydraulic systems
Cutting angle adjustment: Smooth adjustment from 90° to 60° with fixed positions for 60° right and 45° left
Lifting mechanism: Manual lifting of the saw blade frame with adjustable spring tension for optimal lifting force depending on the material type
Material clamping mechanism: The heavy-duty machine features a quick clamp that simplifies the clamping process and ensures stable operation

Advantages and features:
New frame design: The metal cutting band saw machine Pilous ARG 235 features a uniquely designed saw blade frame that improves its rigidity and enhances cutting accuracy. Internal channels for electrical wiring and cooling fluid are protected from damage, which increases the device’s durability
Ease of operation: The easy-lifting system for the frame, with adjustable spring tension, optimizes the working process and reduces the effort required to lift the frame. This improves comfort, especially when working with heavy materials
High productivity: The ability to adjust saw blade speed and material feed allows for optimization based on the characteristics of the material being processed, significantly increasing the overall machine productivity
Reliability and durability: The machine's structure is made from cast iron, providing excellent vibration absorption and increasing operational stability when cutting heavy and hard materials. Additionally, enhanced processing and rotating parts contribute to the longevity of the machine
Flexibility in cutting angle adjustment: Smooth adjustment of the cutting angle from 90° to 60°, along with easy angle fixation on a scale with fixed stops, allows for precise cuts. This simplifies working with angled cuts and makes the process more convenient
Cooling system: The built-in cooling system, with adjustable liquid flow on both guides, helps maintain optimal saw blade temperature and increases its service life by preventing overheating
Automatic machine stop: After completing the cut, the machine automatically stops the saw blade drive, contributing to energy savings and increasing operational safety

You can buy metal cutting band saw machine Pilous ARG 235 at KVERB
If you're looking for a reliable and efficient metal cutting band saw machine, the metal cutting band saw machine Pilous ARG 235 will be an excellent solution for your business. The machine combines modern design, high productivity, and cutting accuracy, making it the perfect choice for cutting various metals. You can buy the metal cutting band saw machine Pilous ARG 235 at KVERB
