Band saw machines Bomar Proline 520.450 H

Band saw machine Bomar Proline 520.450 H is a horizontal band saw machine with a two-column construction, designed for perpendicular cuts on materials with a diameter of up to 450 mm. It combines high performance and quality at an affordable price. The machine features two robust columns, with the saw mechanism mounted on linear guides on one side and auxiliary guides on the other. Excellent performance is ensured by features such as a three-sided carbide precision guide unit for the 34 mm wide blade and synchronized brushes for chip removal. The material is fixed using a full-stroke sectional clamp, and material feed is manual. The cut material discharge is equipped with a sliding mechanism.

This machine is ideal for performing straight cuts on metal workpieces, pipes, profiles, and other materials with a diameter of up to 450 mm. It's a solution for medium and large-scale production that requires high precision and cutting speed.

Technical characteristics Bomar Proline 520.450 H:
Working mode: automatic
Machine type: horizontal band saw machine
Cut type: straight cut
Cutting angle range: 0°
Drive: 4 kW, 3x400 V/50 Hz
Saw speed: from 20 to 120 m/min
Saw dimensions: 6020 x 41 x 1.3 mm
Material loading height: 780 mm
Max material weight: 800 kg
Minimum residual length: 20 mm
Minimum cutting diameter: Ø 10 mm

Machine dimensions:
Length: 2172 mm
Width: 1197 mm
Height: 1771 mm
Weight: 800 kg

Advantages and features Bomar Proline 520.450 H:
Double linear guide for the saw mechanism, ensuring maximum accuracy and stability during cutting.
Smooth pressure adjustment for material feed with automatic regulation, significantly increasing the blade's service life.
High rigidity and reliability of the construction, allowing for reduced cutting time and increased productivity.
Wide speed range adjustment (from 20 to 120 m/min), ensuring optimal cutting conditions depending on the material.
Chip removal system that maintains a clean working area and prevents blade contamination.
