Band saw machines Bomar Individual 820.640 DGH

Band saw machine Bomar Individual 820.640 DGH is an automatic band saw machine with a two-column design, developed for performing precise double-sided angular cuts. Its high performance and reliability are ensured by a rigid frame, advanced guides, and a powerful 54 mm wide blade. The machine is ideal for processing both solid materials and profiles.

Who is Bomar Individual 820.640 DGH suitable for and what is it used for:

Manufacturers of metal structures.
Mechanical engineering and heavy industry plants.
Workshops working with profile metals.
Enterprises engaged in serial production of metal products.
The machine is used for producing elements of metal frames, construction structures, machine parts, profile products, and many others.

Technical specifications of Bomar Individual 820.640 DGH:

Operating mode: automatic.
Machine type: horizontal band saw for angular cutting.
Cutting angle range: from -60° to +60°.
Drive: motor power 5.5 kW, power supply 3×400 V/50 Hz.
Band saw blade speed: 20–120 m/min with adjustment option.
Band saw blade dimensions: 7900×54×1.6 mm.

Maximum cutting dimensions:
At 0°: 820×640 mm.
At 45° R: 560×400 mm.
At 45° L: 580×560 mm.
At 60° R: 380×250 mm.
At 60° L: 400×530 mm.

Material loading height: 810 mm.
Weight: 2500 kg.
Dimensions: length – 3750 mm, width – 2400 mm, height – 2700 mm.

Advantages and features of Bomar Individual 820.640 DGH:

Two-column construction: ensures stability and precision when processing large blanks.
Hydraulic clamping and control: automatic material clamping and blade descent process increases efficiency.
Band saw blade speed adjustment: frequency converter ensures optimal performance and extends blade life.
Reduced cutting time: the blade is tilted at a 2° angle, which reduces cutting time and increases precision.
Wide upgrade options: the machine can be equipped with additional components such as a laser cutting indicator, lubrication system (micronizer), additional lighting, and roller conveyors for material feeding automation.
Convenient control panel: all parameters are adjusted from a single point using intuitive settings.
