Band saw machines Bomar Extend 1820.1520

Band saw machine Bomar Extend 1820.1520 is a horizontal band saw with a two-column construction, designed for straight and perpendicular cutting of large-diameter materials, such as metals and profile materials. This powerful machine offers high precision and stability when processing various materials, making it an ideal choice for large-scale manufacturing enterprises.

It is used for processing large-size materials, including metal pipes, profiles, and other structural elements. Bomar Extend 1820.1520 provides fast and precise cutting with minimal time expenditure, optimizing production processes in industries of various sectors.

Bomar Extend 1820.1520 is suitable for:

Enterprises with large production volumes: ideal for manufacturing structures made of large metal or plastic profiles
Machine-building companies: used for processing complex metal parts, pipes, and beams
Construction companies: designed for cutting large diameters for further use in construction
Metalworking enterprises: designed for high-precision cutting of large metal workpieces and profiles

Technical specifications of Bomar Extend 1820.1520:

Operating mode: automatic
Machine type: horizontal metal cutting band saw machine
Cut type: straight cut
Motor power: 11 kW, 3×400 V/50 Hz
Belt speed: 15–90 m/min
Belt size: 11760×67×1.6 mm
Material loading height: 760 mm
Maximum remnant length: 40 mm
Machine dimensions:
Length: 7,725 mm
Width: 4089 mm
Height: 5,390 mm
Weight: 29,000 kg

Advantages and features of Bomar Extend 1820.1520:

Two-column construction: increases stability and accuracy during cutting, ensuring high-quality work
Hydraulic full stroke clamping: ensures reliable and efficient material holding, making it easier to process large workpieces
Adjustable belt speed: thanks to the frequency converter, the optimal speed can be set for various material types, reducing belt wear and increasing productivity
Polymer concrete technology: vibration resistance allows for accurate cutting results even under high loads
Automatic feed adjustment: the machine automatically adjusts feed based on material resistance, reducing processing time and improving efficiency
Adjustable saw unit tilt: the saw unit can be tilted by 2° or 6° for optimizing the cutting process and extending belt life
Feed flexibility: the machine can be equipped with fully automatic feeding for even greater efficiency

You can buy band saw machine Bomar Extend 1820.1520 at KVERB. We offer:

Delivery in Ukraine
Official warranty and support at all stages (from purchase to commissioning)
Consultation and assistance in selection

Contact our managers now to get the best offer on band saw machine Bomar Extend 1820.1520.
