Metal plate rolling machine Say-Mak SMRM-S 2550x180

Metal plate rolling machine Say-Mak SMRM-S 2550x180 ensures high processing accuracy and complies with European safety standards (CE). The durable welded frame and hot-rolled rolls made of SAE 1050 CK 45 steel guarantee reliability and long-term durability during operation.

The model is designed for forming sheet metal into cylindrical and conical products. It is suitable for working with aluminum, stainless steel, and carbon steel, ensuring the production of precise and high-quality components for various manufacturing tasks.

Applications:

Metalworking enterprises
Manufacturers of ventilation systems
Plants producing tanks, pipes, and metal structures
Mechanical engineering companies
Companies involved in the production of cladding and decorative metal products
Shipbuilding and aircraft manufacturing companies
Producers of components for construction and agricultural machinery

Technical specifications of Say-Mak SMRM-S 2550x180:

Working sheet length – 2550 mm
Pre-bending capacity – 3.0 mm x1.5/4.0 mm x5
Maximum bending thickness – 4 mm x1.5/5 mm x5
Upper and lower roll diameter – 180 mm
Minimum bending radius – 270 mm
Main motor power – 4.0 kW
Rear roll motor power – 1.5 kW
Dimensions (LxWxH) – 4350×950×1300 mm
Weight – 3050 kg

Key advantages:

The overload protection system enhances reliability and extends the service life.
The mobile control panel ensures easy settings adjustment and process control.
The massive welded construction increases load resistance.
The conical bending device allows the creation of conical components.
The centralized lubrication system reduces friction and minimizes component wear.
The brake motor ensures high processing accuracy and safe operation.
The manual drop-end mechanism simplifies the removal of finished workpieces.
Both rolls are driven by a powerful planetary gearbox, ensuring even distribution of force.

You can buy the Metal plate rolling machine Say-Mak SMRM-S 2550x180 at KVERB. We offer:

Delivery in Ukraine
Official warranty and technical support
Professional consultation to help you select the equipment that suits you best

Contact our managers right now to get the best offer for the Metal plate rolling machine Say-Mak SMRM-S 2550x180.
