Metal longitudinal cross cutting machine SLMST 1500 SCHLBACH

Metal longitudinal cross cutting machine with guillotine shears SLMST 1500 SCHLBACH is designed for cutting wide strip material. The equipment combines functionality and precision in longitudinal and cross slitting of metal, allowing to obtain even blanks. The machine is equipped with advanced PLC control with a touch screen for convenient operation.

The model is intended for working with coil and sheet metal, providing longitudinal and cross cutting with high accuracy and productivity. The machine allows producing blanks for further processing and obtaining narrow strips from coils.

Technical specifications SLMST 1500 SCHLBACH
Power supply voltage 400 V 50 Hz 3 phase
Additional options 460 V 50 Hz 3 phase, 230 V 50 Hz 3 phase
Drive power 2.2 kW
Strip width at input from 200 to 1500 mm
Operating speed up to 22 m/min adjustable
Length tolerance ±0.5 mm per 1000 mm
Default number of blade pairs 4
Optionally up to 10 depending on material

Processed materials
Sheet steel 400 N/mm²
Stainless steel 700 N/mm²
Copper, zinc, aluminum up to 1.5 mm with 4 blade pairs
Maximum aluminum thickness up to 2.0 mm with 4 blade pairs

Equipment dimensions 1750 mm x 2270 mm x 1450 mm
Weight about 2450 kg

Advantages and features SLMST 1500 SCHLBACH
Guillotine knives provide a clean cut without burrs
Suitable for a wide range of metal materials
PLC control with 7-inch touch screen ensures intuitive operation
High operating speed and adjustable parameters for specific tasks
Special coating on rollers for delicate feeding and quick clamp system prevent material damage
Convenient access to knives for quick replacement and adjustment
