Lock forming machine Schlebach PMC

SKU 8855-222-005

0 reviews

In stock

SCHLEBACH

Shipping

Pickup (Self-pickup) (For free)
New POST (Up to 100 UAN)
Meest (Up to 100 UAN)

Payment

Payment upon receipt
Cash payment
Payment by bank details

Lock forming machine Schlebach PMC is the basic model of the SPM/PMC series for forming a double standing seam with a height of 25 or 32 mm. The design is made according to the modular principle, which allows the machine to be additionally equipped with extra components if necessary.

The machine is suitable for processing parallel panels in one cycle and conical, trapezoidal, and shaped panels in two cycles. The feed width is smoothly adjustable up to 870 mm. For extended tasks, there is a modification SPM 1000 / PMC 1000 with feed up to 1080 mm. High-quality rollers made of special steel are resistant to wear and corrosion, and elastic mounts of the upper rollers provide gentle processing without marks on the surface.

Schlebach PMC is suitable for:
Manufacturers producing roofing and facade panels
Installation companies working with blanks of various shapes
Companies that require equipment with upgrade capability
Workshops producing both standard and clip lock profiles

Technical specifications:
Drive power: 1.1 kW
Operating speed: 11 m/min
Forming stages: 9
Feed width: 285–870 mm (optionally up to 1080 mm)
Feed height: 890 mm
Axial dimension: 215–800 mm (optionally up to 1010 mm)
Minimum panel length: 500 mm
Weight: 470 kg

Advantages and features:
Modular construction with upgrade capability
Compatibility with 25 and 32 mm profiles
Option with clip lock (PMC)
Smooth feed width adjustment
Rollers made of alloy steel with wear protection
Ball bearing guides for precise feeding
Elastic roller mounts for accurate forming without deformation

You can buy the lock forming machine Schlebach PMC from KVERB company:
We offer:
Delivery throughout Ukraine
Official warranty and technical service
Consultations on selecting equipment for your tasks

Contact our managers and get a personalized offer for Schlebach PMC.

Specifications Lock forming machine Schlebach PMC

Supply voltage 400 V / 50 Hz / 3 Ph.
Drive power 1.1 kW
Operating speed 11 m/min
Forming stages 9 stations
Infeed width 285 – 870
Axial dimension 215 – 800
Infeed height 890
Processable materials <ul> <li>Titanium zinc up to 0.8 mm</li> <li>Copper up to 0.8 mm</li> <li>Aluminium up to 0.8 mm</li> <li>Sheet steel (galvanized and coated) up to 0.7 mm</li> <li>Stainless steel up to 0.5 mm</li> </ul>
WEIGHT 470 kg
LENGTH 1 500 mm
WIDTH 1 500 mm
HEIGHT 1 100 mm
