Circular saw for metal Ileri Teknik DK 370
SKU 9092-100-035
0 reviews
In stock
Ileri Teknik
0 uah.
Shipping
- Pickup (Self-pickup) For free
- New POST Up to 100 uan
- Meest up to 100
Payment
- Оплата при отриманні
- Готівкова оплата
- Оплата по рахунку
The circular metal saw DK 370 Ileri Teknik is designed for batch cutting of metal pipes and profiles at various angles with high precision.
Equipped with servo drives for feeding, rotating the saw head, and vertical movement, this saw enables cutting at angles up to ±60°. The touchscreen panel with a PLC controller supports up to 200 programs, significantly simplifying operation and increasing productivity.
Technical specifications:
Motor power: 4 kW
Power supply: 400 V
Saw blade diameter: 350 mm
Cutting angle: 90° / ±45° / ±60°
Round workpiece diameter: up to 90 mm
Square/rectangular workpiece: up to 90×90 mm
Feeding: automatic, servo drive, ball screw mechanism
Cutting accuracy: ±0.3 mm
Blade speed: 20–80 rpm
Air pressure: 6 bar
Installed power: 6.75 kW
Advantages and features:
Cutting at angles up to ±60°.
Servo drives for feeding, rotation, and movement.
Touchscreen panel with PLC control.
10 cutting length modes for a single material.
Linear guides with roller supports.
Support for up to 200 programs for operational flexibility.
Blade coatings TiN, TiCN, TiAIN to extend service life.
You can purchase the circular metal saw DK 370 Ileri Teknik from KVERB.
We offer:
Delivery in Ukraine.
Official warranty and technical support.
Professional consultation to help you choose equipment that meets your needs.
Contact our managers right now to get the best deal on the circular metal saw DK 370 Ileri Teknik!
Equipped with servo drives for feeding, rotating the saw head, and vertical movement, this saw enables cutting at angles up to ±60°. The touchscreen panel with a PLC controller supports up to 200 programs, significantly simplifying operation and increasing productivity.
Technical specifications:
Motor power: 4 kW
Power supply: 400 V
Saw blade diameter: 350 mm
Cutting angle: 90° / ±45° / ±60°
Round workpiece diameter: up to 90 mm
Square/rectangular workpiece: up to 90×90 mm
Feeding: automatic, servo drive, ball screw mechanism
Cutting accuracy: ±0.3 mm
Blade speed: 20–80 rpm
Air pressure: 6 bar
Installed power: 6.75 kW
Advantages and features:
Cutting at angles up to ±60°.
Servo drives for feeding, rotation, and movement.
Touchscreen panel with PLC control.
10 cutting length modes for a single material.
Linear guides with roller supports.
Support for up to 200 programs for operational flexibility.
Blade coatings TiN, TiCN, TiAIN to extend service life.
You can purchase the circular metal saw DK 370 Ileri Teknik from KVERB.
We offer:
Delivery in Ukraine.
Official warranty and technical support.
Professional consultation to help you choose equipment that meets your needs.
Contact our managers right now to get the best deal on the circular metal saw DK 370 Ileri Teknik!
Specifications Circular saw for metal Ileri Teknik DK 370
- Maximum Saw Blade Size 350 mm
- Maximum workpiece size at 90° Round 90 mm Square 90 × 90 mm Rectangle 100 × 80 mm
- Maximum workpiece size at 45° Round 80 mm Square 80 × 80 mm Rectangle 100 × 40 mm
- Maximum workpiece size at 60° Round 50 mm Square 50 × 50 mm Rectangle 50 × 50 mm
- Installed Power 6.75 kW
- Nominal Current 22.2 A
- Saw Motor Power 4 kW
- Blade Speed 20 - 80 m/min
- WEIGHT 1 940 kg
- LENGTH 2 320 mm
- WIDTH 1 710 mm
- HEIGHT 2 100 мм
